A151 Trafimet Plasma Cutting Torch
$0.00 USD
Key Features
● Basic features: Self-developed control system, multiple safety alarms, smaller size, flexible operation and easy to use.
● More stable: All parameters are visible, real-time monitoring of the status of the whole machine, to avoid problems in advance, more convenient to troubleshoot and solve problems, to ensure the stable operation of the welding head.
● Process: All parameters are visible, the cleaning quality is more perfect.
● Stable parameters and high repeatability: the determined nozzle air pressure and lens state, as long as the laser power is stable, the process parameters must be repeatable. Greatly improve efficiency, while also reducing operator requirements.
Specification
|
Supply Voltge(V) |
220±10%V AC50/60Hz |
|
Placement environment |
Smooth,free from vibration and impact |
|
Temperature of Working Environment |
10—40 |
| Humidity of Working Environment | ＜70 |
| Fiber Length | 10m |
| Cooling Method | Water-Cooling |
| Applicable Wavelength | 1070nm(±10nm) |
| Applicable Power | ≤3000W |
| Collimation | D20*3.5 F50 |
| Focus/ Scan width |
F400 0-150mm F600 0-225mm F800 0-300mm |
| Reflection | 20*15.2 T1.6 |
| Specifications of Protective Glasses | D30*T5 |
| Maximum of Support Pressure | 15bar |
| Adjustment Range of Spot | Line0-300mm |
| Weight | 1.0KG |
