Key Features
1.Digital precise control with multiple intelligent control functions and modes
2. Accurate preset current and voltage and good dynamic characteristics
3. IGBT inverter technology, sufficient current output, gas shielded welding/manual welding
4. Electronic resistance design, short circuit transition waveform control, stable welding arc, small spatter
5. Arc striking function and post-welding ball removing circuit to ensure the success rate of arc striking
6. Digital display of welding current and welding voltage, intuitive and clear operation
7. Split design, large operating radius, suitable for different customer needs
8. Excellent three-prevention function, independent air duct, better heat dissipation and dust prevention
Specification |
|
| Input power voltage (V, HZ) | 380V土15% 50/ 60Hz |
| Input current (A) | 38.5 |
| Rated input power capacity (KVA) | 25 |
| Output current regulation range | 60-500 |
| No-load voltage (V) | 72 |
| Rated output voltage (V) | 15-50 |
| Load duration (%) | 60 |
| Efficiency (%) | 89 |
| Power factor (in COS) | 0.93 |
| Applicable welding wire diameter (mm) | 0.8/1.0/1.2/1.6 |
| Type of wire feeder | Split machine |
| Weight (kg) | 32.5 |
| Overall dimension (mm) | 585*305*600 |
| Insulation class |
F |
| Enclosure protection class | IP21S |
