MZ-1000 IGBT Inverter Submerged Arc Welding Machine
$1950.00 USD
-
-
$0.00 USD
Key Features
● Advanced IGBT Inverter technology, improve the reliability.
● Inverter frequency reach upto 20Khz, decrease the size and the weight.
● Thermal protection.
● Stepless welding current and voltage setting. Can meet different welding processes.
● Auto-compensation for voltage fluctuation.
● Function of getting rid of the welding ball and removing the molten drop which is on the top of the wire.
● Less spatter, deep penetration, beautiful welding seam.
● CE certificate.
Specification
| Model | MIG-270Y | MIG-315Y |
| Rated Input Voltage |
3-380V±15% (1-220V is optional) |
380V±15% |
| Rated Input Power |
8.7KVA |
11KVA |
| No-load Voltage | 50V | 50V |
| Rated Output Voltage |
27.5V |
29.75V |
| Range of Output Current |
50-270A |
50-315A |
| Wire Dia.(mm) | 0.6-1.0 | 0.6-1.2 |
| Duty Cycle | 60% | 60% |
| Insulation Grade | F | F |
| Protection Class | IP21S | IP21S |
| Dimension(mm) | 496x274x462 | 496x274x462 |
| Net Weight | 19kg | 26kg |
