Digital TIG-200 DC Pulse
  • Digital TIG-200 DC Pulse
  • Digital TIG-200 DC Pulse

Digital TIG-200 DC PulseBT004372

Brand: BORTE
$0.00 USD

Note: Different prices will be automatically shown above when you input different level quantity for each relevant specification. Once your quantity lies in “inquiry”, please add it to cart and continue shopping, we will confirm you the price shortly once you submit the order successfully.

Units Price per Unit (1 Unit = 1 Set)
1--19Need to log in
above20Need to log in

This item has been added to shopping cart.

View Shopping Cart  Continue Shopping

Groupbuy Wishlist

Lower Price, Buy Together. We will release the groupbuy for this item by collecting the information from your Groupbuy Wishlist and offer you an unbelievable price.

*

*

*



Key Features

● Full digital controlled.

● 3 in 1 Multi functions includes HF TIG/LIFT TIG/MMA.

● 2T/4T for TIG Welding

● Arc Force and Hot Sart for MMA Welding

● Pulse function makes excellent welding performancee, special for thin material welding.

● Pre flow time is adjustable from 0 to 2 seconds.

● Built-in protection circuit of over temperature and over voltage and over current for better reliability.


Specification

 Model

 Digital TIG 200 DC Pulse

 Input

 AC230V, 50/60Hz

 Rated inputcapacity(kw)

 TIG:4.5  / MMA:7.0

 Duty cycle

 60%@200A, 100%@170A

 Protection Class  IP23S

 Current Range

 TIG:5-200A  / MMA:5-200A

 Pre-flow(S)

 0-2

 Post-flow(S)

 0-10

 Down-slope / Up-slope (S)  0-10

 Pulse Frequency(Hz)

 0.5-200

 Pulse Width(%)

 5-95

Arc Force(MMA)  0-10A
Hot Start(MMA)  0-10A

Dimension(mm)

 400x150x240

N.W(kg)

 7.6

G.W(kg)  12
Ship Dimension(mm)  530*270*390
